Discover the true power of sound with the HV 80,000 CHIPEO amplifier. With unparalleled performance, this amplifier is the perfect choice for those looking for intense and powerful sound. Furthermore, it has thermal and short circuit protection, ensuring that you enjoy the sound without worrying about potential damage to the equipment.
This amplifier is powered by batteries connected in series, as it uses them as its energy source. Member of a unique product line in its category, the HV 80,000 CHIPEO delivers a power of up to 80,000 watts at 0.5 ohm, which makes it ideal for medium and large automotive sound systems. Highlighting everything from sub-bass to mid-range, this amplifier offers high performance and great sound quality.
Experience the true power of sound with the HV 80,000 CHIPEO amplifier, and feel the difference.
(PT) https://www.youtube.com/watch?v=7a7JB4th-WI
| 0.5 Ohm VERSION | Maximum output power @ 300VDC 0.5 Ohm: 80.000W RMS (For competition) 1 Ohm: 40.000W RMS |
|---|---|
| Number of Channels | 01 |
| Output Voltage | 176 ~ 300VDC @ 0.5 Ohm - 14 ~ 24 Batteries |
| Input Sensitivity | 500mV (Level 100%) @ 1 Ohm |
| Aux Input standard | 0.3% |
| Signal to Noise Ratio | >95dB |
| Frequency response | 10Hz ~ 15KHz (-1dB) |
| Efficiency | 90% @ 1 Ohm (At maximum power) |
| Input impedance | 20K Ohms |
| Protection system | Short-circuit on output and in relation to GND, Low/High voltage and thermal protection |
| Power Supply Voltage | Minimum: 150VDC Maximum: 350VDC |
| Consumption at rest | 90mA |
| Maximum music consumption @ 0.5 Ohm | 142A |
| Maximum Sinusoidal Consumption @ 0.5 ohm (100Hz) | 284A |
| Dimensions (H x W x D) | 9.41" x 2.87" x 14.09" (239 x 73 x 358 mm) |
| Weight | 9.48 lb (4.30Kg) |
| EAN | 7908706600414 |
