MD 1200.1 – 4 OHMS

Taramps Amplifier Module Class D (1 Channel 1.200 Watts RMS)

Description

The Taramps MD 1200.1 in the 4-ohms version has been carefully designed with the highest technology, offering high efficiency and performance for various types of car audio systems. This amplifier covers the whole frequency range, that is, it is a FULL RANGE module. It is classified as mono and has a channel with a maximum power of 1200-Watts RMS. Welcome to Taramps audio world.

Product videos

Technical information
Operation class D
Number of Channels 01
Maximum power @ 12.6 VDC - 4 OHMS: 1200W RMS
@ 12.6 VDC - 8 OHMS: 855W RMS
Input Sensitivity 220mV
Signal to Noise Ratio >88dB
Frequency Response 10Hz ~ 20KHz (-3dB)
Crossover high pass (HPF) 10Hz ~80Hz (-12dB/8ª) Variable
Crossover low pass (LPF) 80Hz ~ Full (-12dB/8ª) Variable
bass boost 0 ~ 10.5dB (50Hz)
Thermal Management Smart Cooler (fan controlled by temperature or audio, with 3 speeds)
Efficiency 82%
Input Impedance 10K Ohms
Output Impedance 4 Ohms
protection system Output short circuit / High or Low supply voltage / Thermal protection
Min. Supply Voltage 9VDC
Maximum Power Supply Voltage 16VDC
Consumption at rest 1.8A
Maximum music consumption 58A
Maximum consumption in sinusoidal signal 116A
Dimensions (WxHxD) 8.98" x 2.76" x 6.22" (228 x 70 x 158mm)
Weight 3.96lb (1,80kg)
EAN 7898556844819
